Can anyone please help me understand how this leech line tensioner setup is installed on kites.   A step by step would be great.  I would love to learn how to install a leech line and tensioner that doesn't require me tying up the end lines at the LE caps as shown in the Tom's Le Quartz build instructional.  I would think this setup below, the leech line is sewn in at the wing tips.  I just don't seem to understand how the lines are coming out at the lower spine and up to the bungie properly.

[Ca Ike]

ITs no different than the usual idea.  The leech line is sewn at the wing tip in the lashing loop or tied to the nock.  THe trailing edge reinforcement is left open at the tail and the lines are crossed over the tail nock then larks headed to the bungie.

[Spectra Sport 96]

Thanks! I figured it might have been crossed over the nock but without an actual kite to reference the images eluded to this but wasn't exactly clear.  There are so many different methods to build the same kite its incredible.  So many great ideas!

[Ca Ike]

 Yep right wing leech line crossed and tied to the left bungie, etc.  ITs debatable which way works better but this way is cleaner and you don't risk breaking the leech line as you wear on the wing tip nocks.

[Spectra Sport 96]

Yep right wing leech line crossed and tied to the left bungie, etc.  ITs debatable which way works better but this way is cleaner and you don't risk breaking the leech line as you wear on the wing tip nocks.

Any techniques or tricks to cleanly sew the leech line into the wing tip?

[Krijn]

This is how i did it on my Sixth Sense UL, but I have to add that I was just copying Sugarbaker's tricks on the Sixth Sense STD he build me.
It is the leechline and loop in one. Leechline with a bungiecord from tail to centrecross.




Krijn

[photogbill]

I hope I'm not too late to help you but I use a 'Plastic' Sewing Needle to 'slide' my leech lines through the TE of the kite AFTER the TE strip is sewn onto the TE. It works great and avoids damaging anything & a lot easier than trying to put the leech line inside the TE strip before sewing & hoping you don't sew over top of the leech line. Just make sure you don't sew your TE strip too close to the TE. You need to leave room for the plastic sewing needle with the leech line to be slid through the TE strip.

You just work the 'needle' through the TE strip pocket with  your thumbnail!

You can purchase them at JoAnn's Fabrics Stores.
Here's a link to the item: http://www.joann.com/plastic-sewing-needles-2-pkg/xprd1144630/

They look like this:

[Spectra Sport 96]

Hmmm.. didn't realize Dritz had that in plastic.  I'll be grabbing that tomorrow, thanks!

[photogbill]

Hmmm.. didn't realize Dritz had that in plastic.  I'll be grabbing that tomorrow, thanks!

Your welcome! LIke I mentioned ...you need to thread the leech line (i use 50# bridle line for mine) in the eylet leaving plentso it doesn't pull out while your sliding it through the TE tunnel!

I hold the trailing edge and kinda pinch the back of the eyelet to inch the needle thru the tunnel ...once it's inside. because it's plastic ...it slides fairly easy.

Good luck and Glad I could help!

[KaoS]

Hmmm.. didn't realize Dritz had that in plastic.  I'll be grabbing that tomorrow, thanks!

They are tapestry needles. Even the metal ones have a blunt, rounded tip.  Ideal for this work... and splicing braided line... and sleeving flying lines...
